Fuji CP6 / CP7 8mm Pneumatic SMT Feeder for CP6 CP7 Mounter

Fuji CP6 / CP7 8mm Pneumatic SMT Feeder Overview

The Fuji CP6 / CP7 8mm Pneumatic SMT Feeder is a heavy-duty mechanical-pneumatic tape feeder engineered for high-speed continuous feeding on Fuji rotary turret chip shooter platforms. Built with robust alloy castings, hardened drive ratchets, and high-precision mechanical indexers, this 8mm feeder ensures ultra-fast component advance synchronized with turret placement cycles, minimizing tape vibration and pickup errors for miniature passive components.

Compatible Equipment & Machine Models

This 8mm feeder is engineered specifically for Fuji high-speed chip shooter equipment:

• Fuji CP6 Series: CP6, CP642, CP642E, CP643, CP643E high-speed placement machines
• Fuji CP7 Series: CP7, CP732, CP742, CP743 turret chip shooters
• Fuji CP8 Series: CP8, CP842 series high-speed mounters
• Support & Calibration: Fully compatible with standard CP-series feeder setup carts and mechanical calibration fixtures

Key Parameters & Precision Engineering

• Applicable Tape Width & Pitch: 8mm carrier tape width / standard 2mm and 4mm mechanical pitch configuration
• Supported Carrier Media: Pressed paper tape and embossed plastic blister tape
• Actuation Mechanism: High-reliability pneumatic cylinder and mechanical drive linkage matching high-speed turret indexing speeds
• Chassis & Drive Construction: Wear-resistant forged alloy body with hardened tool steel ratchet teeth and low-friction tape guide channels
• Operational Lifespan: Industrial design rated for over 10,000,000 continuous pick-and-place cycles

Assembly Applications & Component Range

The Fuji CP6 / CP7 8mm feeder is an essential production workhorse in high-volume electronics assembly, including consumer electronics, power supplies, LED drivers, and industrial controllers. It reliably feeds standard miniature passive components:

• Standard SMD chip resistors: 0402, 0603, 0805, and 1206 footprints
• Multilayer ceramic chip capacitors (MLCC) and tantalum capacitors
• Small-signal diodes, transistors (SOT-23, SOD-323), and miniature LEDs packaged in 8mm tape

Quality Standards & Condition Options

We provide verified procurement options based on your production schedule and budget:

• Original New: Authentic factory-original Fuji cassette feeder units in original factory packaging.
• Tested Refurbished: Complete ultrasonic cleaning, pneumatic cylinder pressure testing, ratchet backlash calibration, and 500-cycle advance test runs on dedicated factory calibration jigs.
• Warranty Coverage: Backed by a 3-month to 1-year operational warranty with outgoing test video inspection.

Related Fuji SMT Feeders & Accessories

Explore complementary feeder sizes and placement accessories for your Fuji SMT production lines:

• Fuji NXT W08 / W08C 8mm Electric SMT Feeder
• Fuji NXT W08F 8mm Electric SMT Feeder
• Fuji NXT W12 / W12C 12mm Electric SMT Feeder
• Fuji NXT W16 / W16C 16mm Electric SMT Feeder
• Fuji NXT W24 / W24C 24mm Electric SMT Feeder

Technical Specifications Reference

Parameter	Specification
Brand	Fuji
Series	CP/XP Series (Turret Pneumatic / Mechanical Feeder)
Model / Part Numbers	CP6 / CP7 8mm Feeder
Category Tag	Pneumatic Feeder
Applicable Tape Width	8 mm Paper and Embossed Plastic Carrier Tape
Feeding Pitch	2 mm / 4 mm Mechanical Indexing
Drive Mechanism	Pneumatic actuator cylinder with mechanical ratchet step advancement
Condition	Condition to be confirmed upon inquiry (Original New / Tested Refurbished)
Quality Testing	100% pneumatic cylinder air-leak check, ratchet pawl clearance inspection, and 500-cycle advance test
Minimum Order Quantity	1 Piece
